This product has been discontinued by the manufacture and is no longer available.
KitchenAid Kitchenaid® 27" Double Wall Ovens With Air Fry Mode
Model: KOED527PBS
+3more
Color : Black Stainless Steel with PrintShield™ Finish
Key Features
Integrated Meat Thermometer
Description
Get the crisp you crave, right from your oven. KitchenAid® Double Wall Ovens with Air Fry Mode circulate hot air around the included basket to cook with less oil.* An integrated thermometer takes the guesswork out of roasting meat just the way you like.
*When compared to deep frying.
Read More*When compared to deep frying.
Documents
Available from Appliances Outlet, serving customers throughout Cinnaminson.
Features
Specifications
Features
Integrated Meat Thermometer
Takes the guesswork out of roasting meat just the way you like, from rare to well done. It continuously monitors cooking progress and automatically turns the oven off when your desired temperature is reached.
Specifications
Controls
| Control Type | Glass Touch Digital Display |
| Display Color | White |
| Electronic Display Type | Digital |
| Language Conversion | English/French/Spanish |
| Light Control | Oven Light Touch Pad |
Details
| Oven Automatic Shut-Off | Yes |
| Delay Clean | No |
| Flush Installation Approved | Yes |
| Fuel Type | Electric |
| Oven Type | Double |
| Power On Indicator Light | Yes |
Certifications
| ADA Compliant | No |
| CUL | Yes |
| UL | Yes |
| Star K Certified | Star K Certified |
Electrical
| Amps | 40 |
| Hz | 60 |
| Power Cord Included | No |
| Volts | 240 |
Dimensions & Weight
| Width | 29.75 in. |
| Height | 50.81 in. |
| Length | 27.13 in. |
| Weight | 240 lbs. |
| Carton Depth | 31 |
| Carton Height | 53 |
| Carton Width | 31 1/2 |
| Cutout Depth (in) | 24 |
| Cutout Height (in) | 50 1/4 |
| Cutout Width (in) | 25 1/2 |
| Depth Closed Excluding Handles | 24 1/2 |
| Depth Closed Including Handles | 27 1/8 |
| Depth With Door Open 90 Degree | 46 3/4 |
| Gross Weight | 240 |
| Net Weight | 218.0 |
| Cutout Depth(IN,inches) | 24.0000 |
| Cutout Height(IN,inches) | 50.2500 |
| Cutout Width(IN,inches) | 25.5000 |
| Depth Closed Excluding Handles(IN,inches) | 24.5000 |
| Depth Closed Including Handles(IN,inches) | 27.1250 |
| Depth With Door Open 90 Degree(IN,inches) | 46.7500 |
| Maximum Height(IN,inches) | 51.2500 |
| Minimum Height(IN,inches) | 50.8125 |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 34.75 in. |
| Shipping Height | 55.81 in. |
| Shipping Length | 32.13 in. |
| Shipping Weight | 280 lbs. |
| Total of Shipping Weight | 280 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 23.73 ft³ |
| Dimensional Weight | 294.99 lbs. |
| Total of Cubes | 23.73 ft³ |
| Total of Dimensional Weight | 294.99 lbs. |
Exterior Details
| Door Type | Metal & Glass |
| Oven Window Size | Extra Large |
| Door Lock | Yes |
| Handle Color | Stainless Steel |
| Handle Material | Metal |
Oven Cavity Details
| Bake Element Power | 2,800 W Both |
| Broiler Element Power | 4,000 W Both |
| Broiler Location | Top of Oven |
| Convection Element Type | True Convection |
| Convection Functions | Bake, Broil, Convection Conversion |
| Door Broil Position | Closed |
| Door Lock | Yes |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Installable Under Cooktop | No |
| Interior Coating | Porcelain |
| Light Type | Halogen |
| Lower Oven Capacity | 4.3 cu. ft. |
| Lower Oven Number of Oven Lights | 2 |
| Number of Bake Elements | 2 |
| Number of Broil Elements | 1 |
| Number of Lower Oven Racks | 3 |
| Number of Lower Rack Guides | 6 |
| Number of Upper Oven Racks | 3 |
| Number of Upper Rack Guides | 6 |
| Oven Cleaning Type | Self-Cleaning |
| Self-Cleaning Oven Racks | No |
| Upper Oven Capacity | 4.3 cu. ft. |
| Upper Oven Number of Oven Lights | 2 |
| Convection Element Power | 3,200 Both w |
| Interior Color | Blue Graphite |
Dimensions
| Capacity | 8.6 cu. ft. |
| Common Size | 27 in |
| Cutout Depth | 24 in |
| Gross Weight | 240 lbs |
| Lower Oven Interior Depth | 19 in |
| Lower Oven Interior Height | 18 in |
| Lower Oven Interior Width | 22 in |
| Net Weight | 218 lbs |
| Upper Oven Interior Depth | 19 in |
| Upper Oven Interior Height | 18 in |
| Upper Oven Interior Width | 22 in |
| Cutout Height | 50.25 in |
| Cutout Width | 25.5 in |
| Depth | 27.125 in |
| Depth Closed Excluding Handles | 24.5 in |
| Depth Closed Including Handles | 27.125 in |
| Depth With Door Open 90 Degree | 46.75 in |
| Height | 50.8125 in |
| Maximum Height | 51.25 in |
| Minimum Height | 50.8125 in |
| Width | 26.75 in |
Smart Compatibility
| Connectivity | No |
| Works With | No |
