This product has been discontinued by the manufacture and is no longer available.
Whirlpool Gold® 10 cu. ft. Double Wall Oven with True Convection Cooking
Model: WOD93EC0AH
Color : White Ice
Available from Appliances Outlet, serving customers throughout Cinnaminson.
Specifications
Specifications
Certifications
| ADA Compliant | No |
| Prop 65 | Standard |
| UL | Yes |
Oven Cavity Details
| Bake Element Power | 2,800 W Both |
| Broiler Element Power | 3,600 W Both |
| Broiler Location | Top Center Both |
| Convection Element Power | 2,500 w |
| Convection Element Type | True |
| Convection Functions | Bake Broil Roast Upper, Convection Conversion Upper |
| Door Broil Position | Closed |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Interior Coating | Porcelain |
| Interior Color | Grey |
| Lower Oven Capacity | 5 cu. ft. |
| Lower Oven Number of Oven Lights | 2 |
| Number of Bake Elements | 1 |
| Number of Lower Oven Racks | 2 |
| Number of Lower Rack Guides | 6 |
| Number of Upper Oven Racks | 3 |
| Number of Upper Rack Guides | 6 |
| Oven Cleaning Type | Steam Clean |
| Oven Cooking System | Convection Upper/Thermal Lower |
| Upper Oven Capacity | 5 cu. ft. |
| Upper Oven Number of Oven Lights | 2 |
Exterior Details
| Door Type | Glass Window |
| Handle Color | Stainless Steel |
| Handle Material | Metal |
| Oven Window Size | Extra Large Upper and Lower Oven |
Details
| Fuel Type | Electric |
| Oven Configuration | Double Oven |
| Oven Selections | Audible Signal, Automatic Door Latch, Cancel/Off, Clock, Control Lock, Cook Time Indicator, Delay Start, Keep Warm Setting, Rapid Preheat, Sabbath Mode, Timer, Warm Hold |
| Oven Type | Double |
| Power On Indicator Light | Yes |
Controls
| Control Type | Electronic Touch |
| Display Color | Blue, Red |
| Electronic Display Type | Digital |
Refinements
| Features | FIT System, Sabbath Mode/Star-K Certification, Self Cleaning |
Electrical
| Amps | 40 |
| Hz | 60 |
| Volts | 240 |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 23.64 ft³ |
| Dimensional Weight | 293.86 lbs. |
| Total of Cubes | 23.64 ft³ |
| Total of Dimensional Weight | 293.86 lbs. |
Dimensions & Weight
| Width | 30 in. |
| Height | 51.5 in. |
| Length | 26.44 in. |
| Weight | 266 lbs. |
| Cutout Depth | 24 in |
| Cutout Height | 50-1/4 in |
| Cutout Width | 28-1/2 in |
| Depth Closed Excluding Handles | 24-1/2 in |
| Depth With Door Open 90 Degree | 46-3/4 in |
| Gross Weight | 266 lbs |
| Lower Oven Interior Depth | 19 in |
| Lower Oven Interior Height | 18 in |
| Lower Oven Interior Width | 25 in |
| Upper Oven Interior Depth | 19 in |
| Upper Oven Interior Height | 18 in |
| Upper Oven Interior Width | 25 in |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 56.5 in. |
| Shipping Length | 31.44 in. |
| Shipping Weight | 306 lbs. |
| Total of Shipping Weight | 306 lbs. |
| Source | Calculation |
Other
| Capacity | 10 cu. ft. |
| Common Size | 30 in |
