This product is discontinued and has been replaced by the model below.
KitchenAid 30" Single Wall Oven with Even-Heat™ True Convection
Model: KOSE500EWH
+2more
Color : White
Replaced By
30-inch Smart Electric Single Wall Oven With Assisted Cooking Modes - White
Model: KOES730SWH
$2,599.00
Was$3,610.00Save $1,011.00 (28%)
Description
This 30" Single Wall Oven with Even-Heat™ True Convection provides consistent heating and even cooking. A unique bow-tie shaped design and convection fan helps ensure there’re no burnt edges or undercooked centers. The Temperature Probe delivers accurate measurement of internal temperatures of meats, poultry, and casseroles without opening the oven door for perfectly cooked food. The oven’s bold design details are the perfect balance of elegance and functionality.
Read More
Available from Appliances Outlet, serving customers throughout Cinnaminson.
Specifications
Specifications
Controls
| Control Type | Glass Touch Digital Display |
| Display Color | White |
| Electronic Display Type | Digital |
| Language Conversion | English/French |
| Light Control | Oven Light Touch Pad |
Details
| Oven Automatic Shut-Off | Yes |
| Cooktop Combinations | KCES550, KCES556, KCES950, KCES956, KCGS350, KCGS356, KCGS550, KCGS556, KCGS950, KCGS956, KECC604, KECC607, KECC664, KECC667, KGCC506, KGCC566, KICU509, KICU569 |
| Flush Installation Approved | Yes |
| Fuel Type | Electric |
| LP Convertible | No |
| Oven Configuration | Single Oven |
| Oven Selections | Clock, Control Lock, Delay Start, Proofing, Sabbath Mode, Star K, Temperature Probe, Time Bake, Timer |
| Oven Type | Single |
Certifications
| ADA Compliant | No |
Electrical
| Amps | 20 |
| Hz | 60 |
| Power Cord Included | No |
| Volts | 240 |
Other
| Capacity (Cu Ft) | 5.00 |
Dimensions & Weight
| Width | 30 in. |
| Height | 28.75 in. |
| Length | 27.13 in. |
| Weight | 160 lbs. |
| Carton Depth | 30 13/16 |
| Carton Height | 30 3/4 |
| Carton Width | 34 13/16 |
| Cutout Depth (in) | 24 |
| Cutout Height (in) | 28 |
| Cutout Width (in) | 28 1/2 |
| Depth Closed Excluding Handles | 24 1/2 |
| Depth With Door Open 90 Degree | 46 3/4 |
| Gross Weight | 160 |
| Net Weight | 144.0 |
| Cutout Depth(IN,inches) | 24.0000 |
| Cutout Height(IN,inches) | 28.0000 |
| Cutout Width(IN,inches) | 28.5000 |
| Depth Closed Excluding Handles(IN,inches) | 24.5000 |
| Depth With Door Open 90 Degree(IN,inches) | 46.7500 |
| Net Weight(LB,pounds) | 144 |
| Carton Depth(IN,inches) | 30.8125 |
| Carton Height(IN,inches) | 30.7500 |
| Carton Width(IN,inches) | 34.8125 |
| Cutout Height Min(IN,inches) | 28.0000 |
| Gross Weight(LB,pounds) | 160 |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 33.75 in. |
| Shipping Length | 32.13 in. |
| Shipping Weight | 200 lbs. |
| Total of Shipping Weight | 200 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 13.54 ft³ |
| Dimensional Weight | 168.31 lbs. |
| Total of Cubes | 13.54 ft³ |
| Total of Dimensional Weight | 168.31 lbs. |
Oven Cavity Details
| Bake Element Power | 2,800 W |
| Broiler Element Power | 4,000 W |
| Broiler Location | Top of Oven |
| Convection Element Power | 3,200 w |
| Convection Element Type | True |
| Convection Functions | Bake, Broil, Roast |
| Door Broil Position | Closed |
| Door Lock | Yes |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Installable Under Cooktop | Yes |
| Interior Coating | Porcelain |
| Interior Color | Blue |
| Light Type | Halogen |
| Number of Bake Elements | 1 |
| Number of Broil Elements | 1 |
| Number of Oven Lights | 2 |
| Number of Oven Racks | 3 |
| Number of Rack Guides | 6 |
| Oven Cleaning Type | Adjustable Self Cleaning |
| Oven Cooking System | Convection |
| Oven Rack Guide Type | Molded |
| Self-Cleaning Oven Racks | No |
| Temperature Conversion | Yes |
Exterior Details
| Door Lock | Yes |
| Door Type | Metal & Glass |
| Handle Color | Stainless Steel |
| Handle Material | Metal |
| Oven Window Size | Extra Large |
Dimensions
| Capacity | 5 cu. ft. |
| Common Size | 30 in |
| Cutout Depth | 24 in |
| Cutout Height | 28 in |
| Cutout Width | 28-1/2 in |
| Depth | 27-1/8 in |
| Depth Closed Excluding Handles | 24-1/2 in |
| Depth With Door Open 90 Degree | 46-3/4 in |
| Gross Weight | 160 lbs |
| Height | 28-3/4 in |
| Net Weight | 144 lbs |
| Oven Capacity | 5 cu. ft. |
| Oven Interior Depth | 19 in |
| Oven Interior Height | 18 in |
| Oven Interior Width | 25 in |
| Width | 30 in |
