GE Altitude Series 208-230V 18,000 BTU Single-Zone Ductless Highwall Indoor Unit
Model: ASYW18PRDWB
Color : Other
Key Features
Easy Install Features
3-D Air Flow
Long Distance Air Supply
Auto Louver
Warm Start
SmartHQ Home
Blue Fin
Turbo Mode
Documents
Available from Appliances Outlet, serving customers throughout Cinnaminson.
Features
Easy Install Features
Loaded with features installers love such as an easy installation clip and a quick mount wall bracket
3-D Air Flow
Designed to deliver air vertically and horizontally for even distribution and optimal comfort throughout the room
Long Distance Air Supply
Enjoy comfort made easy with a louver that adjusts airflow upward when cooling, or downward when heating
Auto Louver
Adjusts airflow upward when colling or downward when heating
Warm Start
Get warm quickly with a fan that will not blow cold air during heating mode startup
SmartHQ Home
Homeowners can monitor status, adjust temperature, and set cooling and heating schedules from anywhere using your smartphone. WiFi adapter QAWF01A required (sold separately)
Blue Fin
A special coating that whisks away condensate water
Turbo Mode
Cools or heats the room quickly
ODU Compatibility
Compatible with ASH118PRDWA Outdoor Unit
See specification book for full heating, cooling, and system details
Certifications
ADA Compliant
Specifications
FEATURES
| Outdoor Model to Complete Single Zone System | ASH118PRDWA |
| Model Type | Indoor |
| Indoor Sound Level | 34 |
| Indoor Sound Level | 36 |
| Indoor Sound Level | 42 |
| Indoor Sound Level | 46 |
| Indoor Sound Level | 48 |
| Outdoor Model to Complete Multi Zone System | Single Zone System Only |
| System | 18K Altitude |
| Product Type | Single Zone |
| Fan Speed Stages | 5+ Auto |
| Style | Highwall |
| Short Description | Altitude 18000 BTU Wall-Mounted Indoor |
| Vapor Refrigerant Line | 1/2" |
| Fan Speed Selections | 5 + Auto |
| Series | Altitude |
POWER / RATINGS
| Voltage/Hertz/Phase | 208-230/60/1 |
| Cooling Rated Capacity BTU/Hr | 17,000 |
APPEARANCE
| Color Appearance | White |
Dimensions & Weight
| Width | 43.88 in. |
| Height | 13.25 in. |
| Length | 9.56 in. |
| Weight | 35.3 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 48.88 in. |
| Shipping Height | 18.25 in. |
| Shipping Length | 14.56 in. |
| Shipping Weight | 75.3 lbs. |
| Total of Shipping Weight | 75.3 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 3.22 ft³ |
| Dimensional Weight | 39.99 lbs. |
| Total of Cubes | 3.22 ft³ |
| Total of Dimensional Weight | 39.99 lbs. |
Warranty
| Parts | 5 Year |
