GE Endure Series 208-230V 18,000 BTU Single-Zone Ductless Highwall Indoor Unit
Model: ASYW18URDEB











Key Features
SmartHQ Home
Easy Install Features
Smart Sensor
3-D Air Flow
Long Distance Air Supply
Warm Start
Quiet Mode
Blue Fin
Documents
Available from Appliances Outlet, serving customers throughout Cinnaminson.
Features
SmartHQ Home
Built-In WiFi allows you to monitor status, adjust temperature, and set cooling and heating schedules from anywhere using your smartphone
Easy Install Features
Loaded with features installers love such as an easy installation clip and a quick mount wall bracket
Smart Sensor
Automatically changes to an energy saving temperature while you are away, then back to your regular setting when you return
3-D Air Flow
Designed to deliver air vertically and horizontally for even distribution and optimal comfort throughout the room
Long Distance Air Supply
Enjoy comfort made easy with a louver that adjusts airflow upward when cooling, or downward when heating
Warm Start
Get warm quickly with a fan that will not blow cold air during heating mode startup
Quiet Mode
Maintain comfort levels while minimizing indoor noise with quiet mode
Blue Fin
A special coating that whisks away condensate water
ODU Compatibility
Compatible with ASH118URDEB Outdoor Unit
See specification book for full heating, cooling, and system details
Specifications
FEATURES
| Fan Speed Selections | 5 + Auto |
| Fan Speed Stages | 5+ Auto |
| Indoor Sound Level | 47 dBA |
| Indoor Sound Level | 41 dBA |
| Indoor Sound Level | 38 dBA |
| Indoor Sound Level | 35 dBA |
| Indoor Sound Level | 29 dBA |
| Outdoor Model to Complete Multi Zone System | Single Zone System Only |
| Outdoor Model to Complete Single Zone System | ASH118URDEB |
| Product Type | Single Zone |
| Series | Endure |
| Short Description | Endure 18,000 BTU Wall-Mounted Indoor |
| Style | Highwall |
| System | 18K Endure |
| Unit Type | Indoor |
| WiFi Connect | Built-In |
| WiFi Connect | SmartHQ Home Built-In |
| Connected Capabilities | Amazon Alexa |
| Connected Capabilities | Google Home |
APPEARANCE
| Color Appearance | White |
WEIGHTS & DIMENSIONS
| Approximate Shipping Weight | 46.297 lb |
| Liquid O.D. Refrigerant Line | 1/4" |
| Net Weight | 34.2 lb |
| Overall Depth | 9.0625 in |
| Overall Height | 13.25 in |
| Overall Width | 44.375 in |
| Suction O.D. Refrigerant Line | 1/2" |
POWER / RATINGS
| Cooling Rated Capacity BTU/Hr | 17,800 |
| Voltage/Hertz/Phase | 208-230/60/1 |
Warranty
| Parts | 5 Year |
